Model No: PL63/PL63A
Place of Origin:China
Delivery time: 3-4 weeks
Supply ability: 1000PCS/week
Payment way: T/T, L/C, D/P, Western Union

Description:The LED Moving head beam light is designed with 4PCS mini moving head fixtures with 4 x 8 Watt White or 4 x 4in1 10 Watt QUAD RGBW Leds, very fast and precise PAN/TILT Movement which brings a dynamic range of effects to life. The LED VIXION produces outstanding BEAM effects and with bright light output.

Power Supply: AC100-240V, 50-60Hz
Power Consumption: 80W
Light Source: PL-63 4 x 4in1 10 Watt  RGBW
              PL-63A  4 x 8 Watt White Leds
Effect: Color changing,strobe,Dim 0-100%, speed adjustment,etc
           Built in programs,fade
           0-270 degrees Y moving
           4 modes: Auto,DMX,Mater-slave,Sound
           Thermal management system ensures long life of LEDs
           Electronic protection against short circuit
           New software can be updated through dmx port
           4 head light, individually controllable
           Fast and accurate horizontal / vertical rotation
Beam Angle: Dedicated 8°advanced optical system
Strobe: effect with 1~25flashes per second and pulse effect
Pan: 540 degree
Tilt: 270 degree
Preset program: 8 built in programs can be called up via DMX controller
Control mode: DMX512, master-slave and sound activated controllable or auto operation
DMX Channel: 9/28 DMX Channels
Control Panel: LCD display
Connectors: 3 -pin XLR signal connector input and output
Function: Strobe, Dimmer, Color Changing,  Color Mixing
Body: Black cast aluminum case, nice and wide application
Cooling System: Low noise and efficient FAN cooling system
Carton package:
Net Weight: 12KG
Gross Weight: 14KG
Product Dimension: 1030*90*250mm
Carton Packing: 1100*160*310mm (1pcs/CTN)
